PE / PP / PA Nylon Corrugated Flexible Conduit Custom Corrugated Cable Conduit

PE Nylon Corrugated Flexible Conduit

PA Nylon Corrugated Flexible Conduit

Custom Corrugated Cable Conduit

Place of Origin:

shenzhen, Guangdong, China

Certification:

RoHS 2.0

Chat Now

Request A Quote

Product Details

Name:

PE / PP / PA Nylon Corrugated Conduit

Color:

Custom Sizes And Colors Are Available Upon Customer Request.

Product Certification:

RoHS2.0

Product Structure:

Both Inner And Outer Surfaces Are Corrugated

Highlight:

PE Nylon Corrugated Flexible Conduit

PA Nylon Corrugated Flexible Conduit

Custom Corrugated Cable Conduit

Payment & Shipping Terms

Packaging Details

carton，Customizable as per your demands.

Delivery Time

3-5work days

Payment Terms

T/T

PE / PP / PA Nylon Corrugated Conduit

Product Introduction

Product Structure: Both inner and outer surfaces are corrugated.

Colors: Black, orange, gray, white, red, blue, yellow, etc. (Custom colors available; split‑type version can be provided upon request).

Temperature Resistance:
‑ PE: -40°C ~ 100°C, short‑term 110°C (240h)

‑ PP: -40°C ~ 110°C, short‑term 130°C (240h)
‑ PA Nylon: -40°C ~ 130°C, short‑term 150°C (240h)
‑ Modified PA Nylon: -40°C ~ 150°C, short‑term 175°C (240h)

Flame Retardant Rating:
‑ PP: UL94‑V2
‑ Nylon PA6: UL94‑V0, burning rate ＜100 mm/min

Product Features

Features: Excellent oil‑resistance, acid‑alkali resistance and corrosion resistance; high mechanical strength, good flexibility, glossy surface. Halogen‑free, phosphorus‑free and cadmium‑free, RoHS compliant.
Applications: Specially for new energy vehicle wire harness protection; machinery manufacturing, chemical equipment. Protect cables and wires against external abrasion and provide insulation protection.
Usage: Insert wires and cables into the conduit, then assemble with the matching series of conduit connectors.

Product Dimensions

Close tu ding	Split tu bing	IDxOD(mm)	Curving radius(mm)	Units
SYQ(F)-7.0	SYQ(F)-7.0B	4.5×7.0	10	200
SYQ(F)-9.0	SYQ(F)-9.0B	6.0×9.0	15	200
SYQ(F)-10.0	SYQ(F)-10.0B	6.5×10.0	15	100
SYQ(F)-11.6	SYQ(F)-11.6B:	8.6x11.6	20	100
SYQ(F)-13.0	SYQ(F)-13.0B	10.0x13.0	20	100
SYQ(F)-14.0	SYQ(F)-14.0B	11.0x14.0	25	100
SYQ(F)-15.8	SYQ(F)-15.8B	12.0×15.8	28	100
SYQ(F)-18.5	SYQ(F)-18.5B	14.3×18.5	35	100
SYQ(F)-20.0	SYQ(F)-20.0B	16.0×20.0	38	100
SYQ(F)-20.2	SYQ(F)-20.2B	17.0x21.2	40	100
SYQ(F)-25.0	SYQ(F)-25.0B	20.0x25.0	42	100
SYQ(F)-28.5	SYQ(F)-28.5B	23.0x28.5	45	100
SYQ(F)-30.0	SYQ(F)-30.0B	24.0x30.0	50	100
SYQ(F)-32.0	SYQ-(F)32.0B	25.0x32.0	h5o	100
SYQ(F)-34.5	SYQ(F)-34.5B	29.0×34.5	55	50
SYQ(F)-42.5	SYQ(F)-42.5B	36.0x42.5	70	50
SYQ(F)-54.5	SYQ(F)-54.5B	48.0x54.5	80	25
SYQ(F)-67.2	SYQ(F)-67.2B	56.3 ×67.2	130	20
SYQ(F)-80.0	SYQ(F)-80.0B	66.5×80.0	170	20
SYQ(F)-106.0	SYQ(F)-106B	91.0x106	225	10

Remarks:Corrugated tubes are available in split and non-split types (colors can be customized according to customer requirements).
Any special requirements on color, length and packaging shall be negotiated between the supplier and the buyer.
Our company reserves the right to adjust the inner diameter, outer diameter and structural dimensions.
