Waterproof Cold Shrink Cable End Caps Moisture Proof EPDM End Caps Black

Waterproof Cold Shrink Cable End Caps

Moisture Proof EPDM End Caps

EPDM End Caps Black

Place of Origin:

shenzhen, Guangdong, China

Brand Name:

XingQi

Certification:

RoHS 2.0

Chat Now

Request A Quote

Product Details

Name:

Cold Shrink Cable End Caps

Material:

Ethylene‑Propylene‑Diene Monomer

Operating Temperature:

‑40℃ ~ +90℃

Application:

An Ideal Sealing Product For Communication Cables, Coaxial Cables And Medium & Low‑voltage Power Cables.

Highlight:

Waterproof Cold Shrink Cable End Caps

Moisture Proof EPDM End Caps

EPDM End Caps Black

Payment & Shipping Terms

Packaging Details

carton，Customizable as per your demands.

Delivery Time

3-5 work days

Payment Terms

T/T

Cold Shrink Cable Caps EPDM Cold Shrink End Caps

Product Introduction

The high‑performance rubber sleeve is pre‑expanded during manufacturing and fitted onto a support tube formed by wound spiral core cords. The product enables very convenient on‑site installation, and no heating tools such as blowtorches or hot‑air guns are needed for the whole process. Simply fit the end cap over the cable end and pull out the internal spiral supporting strip.

Thanks to the excellent elastic‑memory property of EPDM rubber, once the inner supporting strip is removed, the rubber end cap will automatically shrink under its own elastic force and fit tightly in place. It forms a well‑sealed, stable and long‑lasting insulating protective layer for the cable termination, and delivers effective insulation, waterproof and moisture‑proof sealing performance.

Application

Suitable for end‑termination sealing of various cable types as listed in the example table below:
‑ Cables with outer sheaths of EPR, XLPE, PVC, LSOH and other materials;
‑ Lead‑sheathed cables;
‑ Various armoured wires and braided‑armoured cables.

Product Dimensions

Model No.	Specification Expanded Size * Fully‑recovered Length	Min. Sealing Diameter (mm)	Max. Sealing Diameter (mm)
FM‑1	Φ25*60	11.6	20.9
FM‑2	Φ35*75	15.9	30.1
FM‑3	Φ55*82	26.0	49.2
FM‑4	Φ90*100	45.5	84.3

Product Advantages
Heating‑free & Safe Installation
Pre‑expanded cold‑shrink design. No blowtorch or hot‑air gun required. Simply slip onto cable end and pull out the spiral supporting strip for fast completion. No open‑fire risk, suitable for confined working space.
Superior Insulation & Sealing Performance
Made of EPDM rubber with excellent elastic‑memory property. It tightly clamps the cable sheath after recovery, providing stable radial compression. Good insulation, waterproof, moisture‑proof and dust‑proof performance, preventing moisture and contaminants from entering cable termination.
Wide Compatibility
Compatible with cables with XLPE, EPR, PVC, LSOH outer sheaths, lead‑sheathed cables, various armoured and braided‑armoured cables. Suitable for multiple working conditions.
Excellent Weather Resistance & Long Service Life
EPDM material features great ageing, UV and environmental corrosion resistance. It works reliably for long‑term application in outdoor, underground and humid environments, sealing performance will not degrade easily over time.

Remarks: Custom sizes and colors are available upon customer request.
