Place of Origin:
Shenzhen, Guangdong, China
Brand Name:
XingQi
Certification:
RoHS2.0
Made of premium silicone rubber, it features soft texture, high temperature resistance and stable performance. Widely used for insulation protection of various household appliances, industrial electrical equipment, lighting fixtures and electronic instruments. It delivers outstanding resistance to high temperature, acid & alkali corrosion and corona discharge.
Customization Services :
Customization is available for inner diameter, wall thickness, shrink ratio, cut lengths and special color formulas.
Application Fields : Insulators, Electrical Winding Insulation, Winding Wire Coating Insulation, Electrical Base, Shell, Motor, Insulating Varnish, Switch Baseplate, Hooka, Aquarium, Coffee Machine etcs.
english
français
Deutsch
Italiano
Русский
Español
português
Nederlandse
ελληνικά
日本語
한국
polski
فارسی
বাংলা
ไทย
tiếng Việt
العربية
हिन्दी
Türkçe
indonesia
Product Features
l Operating Temperature: -50℃ ~ +200℃
l Environmental Standard: RoHS
l Properties: Heat resistant, flexible, high voltage resistant, acid & alkali resistant
l Standard Color: Transparent (custom colors available)
Product Parameters
|
Performance Item |
Test Method |
Specification Requirement |
|
|
Flame Retardant |
Non-Flame Retardant |
||
|
Tensile Strength(MPa) |
ASTM D 2671 |
≥5.0 |
≥5.0 |
|
Elongation at Break(%) |
ASTM D 2671 |
≥200 |
≥300 |
|
Tear StrengthKN/m |
300°C×1h |
≥14.5 |
≥18.5 |
|
Flammability |
ASTM D 2671 B |
VW-1 |
HB |
|
Dielectric Strength(kV/mm) |
IEC243 |
≥20 |
≥20 |
|
Volume resistance (0·cm) |
ASTM D876 |
≥2×10" |
2×10" |
Product Dimensions
|
Dimension(mm) |
Pre-shrink ID (mm) |
Standard Wall Grades(mm) |
||
|
2500V |
4000V |
7000V |
||
|
Φ0.8 |
0.8+0.2/-0.1 |
0.5±0.1 |
0.8±0.1 |
1.0±0.1 |
|
Φ1 |
1.0+0.2/-0.1 |
0.5±0.1 |
0.8±0.1 |
1.0±0.1 |
|
Φ1.5 |
1.5+0.2/-0.1 |
0.5±0.1 |
0.8±0.1 |
I.0±0.1 |
|
Φ2 |
2.0+0.2/-0.1 |
0.5±0.1 |
0.8±0.1 |
1.0±0.1 |
|
Φ2.5 |
2.5±0.2/-0.1 |
0.5±0.1 |
0.8±0.1 |
1.0±0.1 |
|
Φ3 |
3.0+0.2/-0.1 |
0.5±0.1 |
0.8±0.1 |
1.0±0.1 |
|
Φ3.5 |
3.5+0.2/-0.1 |
0.5±0.1 |
0.8±0.1 |
1.0±0.1 |
|
Φ4 |
4.0±0.2/-0.1 |
0.5±0.1 |
0.8±0.1 |
1.0±0.1 |
|
Φ4.5 |
4.5+0.2/-0.1 |
0.5±0.1 |
0.8±0.1 |
1.0±0.1 |
|
Φ5 |
5.0±0.2 |
0.5±0.1 |
0.8±0.1 |
1.0±0.1 |
|
Φ6 |
6.0±0.2 |
0.5±0.1 |
0.8±0.1 |
1.0±0.1 |
|
Φ7 |
7.0±0.2 |
0.5±0.1 |
0.8±0.1 |
1.0±0.1 |
|
Φ8 |
8.0±0.2 |
0.5±0.1 |
0.8±0.1 |
1.0±0.1 |
|
Φ9 |
9.0±0.2 |
0.5±0.1 |
0.8±0.1 |
1.0±0.1 |
|
Φ10 |
10.0±0.2 |
0.5±0.1 |
0.8±0.1 |
1.0±0.1 |
|
Φ11 |
11.0±0.2 |
0.5±0.1 |
0.8±0.1 |
1.0±0.1 |
|
Φ12 |
12.0±0.2 |
0.5±0.1 |
0.8±0.1 |
1.0±0.1 |
|
Φ13 |
13.0±0.2 |
0.5±0.1 |
0.8±0.1 |
1.0±0.1 |
|
Φ14 |
14.0±0.2 |
0.5±0.1 |
0.8±0.1 |
1.0±0.1 |
Remarks: Custom sizes and colors are available upon customer request.
