Name: Noise Reduction Self Wrapping Sleeve RoHS Compliant Wire Harness Sleeve
Brand: Shenzhen Xingqi Plastic Products Co., Ltd.
SKU: XQZJ
Price: Negotiable USD
Availability: InStock

Home > Products > Self Wrapping Sleeve >

Noise Reduction Self Wrapping Sleeve RoHS Compliant Wire Harness Sleeve

Noise Reduction Self Wrapping Sleeve

Self Wrapping Sleeve RoHS Compliant

RoHS Compliant Wire Harness Sleeve

Place of Origin:

shenzhen, Guangdong, China

Brand Name:

XingQi

Certification:

RoHS 2.0

Model Number:

XQZJ

Chat Now

Request A Quote

Product Details

Name:

Self-Wrapping Noise Reduction Sleeve

Color:

Black

Overlap Rate:

25%

Material:

PET Mono & Polyester Fiber

Operating Temperature:

-40℃ ~ +150℃

Highlight:

Noise Reduction Self Wrapping Sleeve

Self Wrapping Sleeve RoHS Compliant

RoHS Compliant Wire Harness Sleeve

Payment & Shipping Terms

Minimum Order Quantity

200M

Packaging Details

carton，Customizable as per your demands.

Delivery Time

3-5work days

Payment Terms

T/T

Product Introduction

This product is precisely woven with high‑performance polyester multifilament and polyester monofilament on warp‑weft single‑spindle knitting machines. It complies with international environmental standards including RoHS, REACH and halogen‑free requirements, free of hazardous substances, ideal for protection of various wiring harnesses and tubes.

Boasting soft texture and light weight, it adopts a special open self‑wrapping structure. No clips or tapes are required for fast wrapping of cables, allowing easy disassembly for later maintenance and cable addition. Its dense uniform woven surface provides outstanding wear‑resistance against scratch and abrasion. It also delivers good noise‑damping performance to eliminate abnormal noise caused by cable vibration and friction, meanwhile neatly organizes scattered wires. Resistant to bending and ageing, it will not crack after long‑term service. Widely applied in automotive wiring harnesses, home appliances, industrial control cabinets and other fields.

Product Features

Item	Parameter
Material	PET mono & polyester fiber
Operating Temperature	-40℃ ~ +150℃
Melting Point	240±10℃
Flame Retardant Rating	Complies with UL94 V-1
Color	black
Overlap Rate	25%
Certifications	RoHS

Product Dimensions

model	Inner Diameter(in)	Max Inner ID	Pack
XQSCWT-003	Φ3	Φ4	100m/roll
XQSCWT-005	Φ5	Φ6	100 m/roll
XQSCWT-008	Φ8	Φ9	100 m/roll
XQSCWT-010	Φ10	Φ11	100 m/roll
XQSCWT-013	Φ13	Φ14	100 m/roll
XQSCWT-016	Φ16	Φ17	100 m/roll
XQSCWT-019	Φ19	Φ20	50 m/roll
XQSCWT-025	Φ25	Φ26	25 m/roll
XQSCWT-029	Φ29	Φ30	25 m/roll
XQSCWT-032	Φ32	Φ34	25 m/roll
XQSCWT-038	Φ38	Φ40	25 m/roll
XQSCWT-050	Φ50	Φ52	25 m/roll

OEM & ODM customization

We support full-process ODM customization for heat shrink tubes. We independently develop material formulas and develop exclusive specifications and special-shaped structures, providing one-stop services including mold opening, sample trial production and mass production, helping customers create differentiated wire harness insulation protection products.

Remarks: Custom sizes and colors are available upon customer request.
