Anti Interference Monofilament Sleeve EMI Shielding Flexible Braided Sleeving Lightweight

Anti Interference Monofilament Sleeve

EMI Shielding Flexible Braided Sleeving

Flexible Braided Sleeving Lightweight

Place of Origin:

shenzhen, Guangdong, China

Brand Name:

XingQi

Certification:

RoHS 2.0

Chat Now

Request A Quote

Product Details

Name:

Self‑Wrapping Monofilament Braided Sleeve

Color:

Black

Overlap Rate:

25%

Material:

PET Mono & Polyester Fiber

Operating Temperature:

-40℃ ~ +260℃

Highlight:

Anti Interference Monofilament Sleeve

EMI Shielding Flexible Braided Sleeving

Flexible Braided Sleeving Lightweight

Payment & Shipping Terms

Minimum Order Quantity

200M

Packaging Details

carton，Customizable as per your demands.

Delivery Time

3-5work days

Payment Terms

T/T

Product Introduction

Manufactured with tinned copper foil yarn and polyester monofilament by warp & weft weaving machine. It complies with environmental certifications including RoHS2.0, REACH and halogen-free requirements. Lightweight and flexible, this open self-wrapping structure provides electromagnetic shielding, anti-interference, abrasion resistance and easy arrangement.

100% woven with high-quality polyester monofilaments via precision warp-weft knitting technology. Compliant with RoHS2.0, REACH and halogen-free standards, the eco-friendly, non-toxic products fit home appliances, new energy and industrial control equipment. Featuring a lightweight, tough open self-wrapping structure, they allow tool-free installation and easy later maintenance. The dense woven structure delivers superior wear resistance, tensile strength and aging resistance to protect wires from damage and prolong service life. The breathable hollow design ensures efficient heat dissipation to avoid overheating and circuit faults. Standard black finish and complete caliber specifications offer great versatility for harness protection, organization and heat dissipation.

Product Features

Item	Parameter
Material	PET mono & polyester fiber
Operating Temperature	-40℃ ~ +260℃
Melting Point	1084±10℃
Flame Retardant Rating	Complies with UL94 V-2
Color	black
Overlap Rate	25%
Certifications	RoHS2.0

Product Dimensions

model	Inner Diameter(in)	Max Inner ID	Pack
XQSCP-003	Φ3	Φ4	100m/roll
XQSCP-005	Φ5	Φ6	100 m/roll
XQSCP-008	Φ8	Φ9	100 m/roll
XQSCP-010	Φ10	Φ11	100 m/roll
XQSCP-013	Φ13	Φ14	100 m/roll
XQSCP-016	Φ16	Φ17	100 m/roll
XQSCP-019	Φ19	Φ20	50 m/roll
XQSCP-025	Φ25	Φ26	25 m/roll
XQSCP-029	Φ29	Φ30	25 m/roll
XQSCP-032	Φ32	Φ34	25 m/roll
XQSCP-038	Φ38	Φ40	25 m/roll
XQSCP-050	Φ50	Φ52	25 m/roll

Product Advantages

Tool‑free installation, fits over finished cable harnesses without wire disassembly.
Strong self‑closing memory, automatically wraps cables with overlapping seam.
Excellent abrasion resistance, flame retardant, halogen‑free & RoHS compliant
Open woven structure for good ventilation & heat dissipation.
Flexible and reusable, convenient for inspection, repair and harness modification.
Reduces harness friction noise, lightweight for automotive & rail harness protection.

Remarks: Custom sizes and colors are available upon customer request.
