Place of Origin:
shenzhen, Guangdong, China
Brand Name:
XingQi
Certification:
RoHS 2.0
| Item | Specification |
|---|---|
| Material | Thermoplastic Polyurethane Elastomer |
| Operating Temperature | -55°C ~ +125°C |
| Key Features | Abrasion‑resistant, hydrolysis‑resistant, high elasticity, soft |
| Environmental Compliance | RoHS Compliant |
| Standard Color | Black (other colors are customizable) |
| Property | Test Method | Requirement |
|---|---|---|
| Tensile Strength(MPa) | UL 224 | ≥10.4 |
| Elongation at Break(%) | UL 224 | ≥200 |
| Tensile Strength after Heat Aging(MPa) | UL 224; 158°C × 168h | ≥7.3 |
| Elongation after Heat Aging(%) | UL 224; 158°C × 168h | ≥100 |
| Cold Bend Resistance | UL 224; -30°C × 1hr | No Cracking |
| Dielectric Withstand Voltage | UL 224 | 4kV, 1min No Breakdown |
| Dielectric Strength(kV/mm) | UL 224 | ≥15 |
| Volume Resistivity(Ω・cm) | UL 224 | ≥1×10¹⁴ |
| Copper Stability | UL 224; 158°C × 168hr | PASS |
| Corrosion Resistance | UL 224; 158°C × 168hr | PASS |
| Flame Retardancy | ASTM D2671 C / GB/T 2408-2008 | VW-1 / V-0 ( Sample Thickness: 3mm) |
| Specification | Model | Fully Recovered Dimensions (mm) - Inner Diameter (ID) | Fully Recovered Dimensions (mm) - Wall Thickness |
|---|---|---|---|
| 1.0 | XQ-PUR-1.0 | 1.00±0.20 | 0.30±0.10 |
| 2.0 | XQ-PUR-2.0 | 2.00±0.20 | 0.30±0.10 |
| 3.0 | XQ-PUR-3.0 | 3.00±0.20 | 0.30±0.10 |
| 4.0 | XQ-PUR-4.0 | 4.00±0.20 | 0.40±0.10 |
| 5.0 | XQ-PUR-5.0 | 5.00±0.20 | 0.40±0.10 |
| 6.0 | XQ-PUR-6.0 | 6.00±0.20 | 0.50±0.15 |
| 7.0 | XQ-PUR-7.0 | 7.00±0.20 | 0.50±0.15 |
| 8.0 | XQ-PUR-8.0 | 8.00±0.20 | 0.60±0.15 |
| 9.0 | XQ-PUR-9.0 | 9.00±0.20 | 0.60±0.15 |
| 10.0 | XQ-PUR-10.0 | 10.00±0.20 | 0.60±0.15 |
english
français
Deutsch
Italiano
Русский
Español
português
Nederlandse
ελληνικά
日本語
한국
polski
فارسی
বাংলা
ไทย
tiếng Việt
العربية
हिन्दी
Türkçe
indonesia
Remarks: Custom sizes and colors are available upon customer request.
Send your inquiry directly to us
