Place of Origin:
shenzhen, Guangdong, China
Certification:
RoHS 2.0
Flexible Heat Shrink Tubing for Gas Pipelines is manufactured from radiation‑crosslinked polyolefin material. With soft and flexible texture and stable shrinkage performance, it delivers outstanding physical, chemical and electrical insulation properties. Featuring great aging‑resistance and abrasion‑resistance, it can withstand daily friction and impact. It is designed to provide thermal insulation and protection for household gas connecting hoses, isolating external high‑temperature heat source to avoid overheating damage, slow down hose aging and reduce potential safety risks. Widely used for protective sleeving on connection hoses of household gas stoves and gas water heaters. Easy for installation, it closely conforms to hose surface after heat shrinking, serving as an ideal supporting protective component for domestic gas pipeline systems.
● Shrink ratio: 2:1
● Start shrink temperature: ≥ +84℃
● Full recovery temperature: ≥ +120℃
●Operating temperature: -55℃ ~ +125℃
● Compliance: RoHS2.0
●Good elasticity,flame‑retardant
● Standard colors:Yellow(other colors available upon request)
| Property | Test Method | Requirement |
|---|---|---|
| Tensile Strength (MPa) | ASTM D 2671 | ≥10.4 |
| Elongation at Break (%) | ASTM D 2671 | ≥200 |
| Tensile Strength after Aging (MPa) | 158℃×168h | ≥7.3 |
| Elongation at Break after Aging (%) | 158℃×168h | ≥100 |
| Longitudinal Change (%) | ASTM D 2671 | -5 ~ +5 |
| Flammability | ASTM D 2671 Method C | VW‑1 |
| Voltage Withstand (600V) | UL 224 | 2500V, 1min No Breakdown |
| Dielectric Breakdown Strength
|
ASTM D 149 | ≥15 |
| Volume Resistivity (Ω·cm) | IEC 60093 | ≥10¹⁴ |
| Size | Supplied ID (mm) | Fully‑recovered ID (mm) | Fully‑recovered Wall Thickness (mm) | Standard Packaging (m/roll) |
|---|---|---|---|---|
| Φ18/9.0 | 18.50±0.50 | ≤9.0 | 0.65±0.10 | 200 |
| Φ22/9.5 | 19.00±0.50 | ≤9.5 | 0.70±0.10 | 200 |
| Φ28/12.7 | 22.00±0.50 | ≤12.7 | 0.70±0.10 | 100 |
| Φ30/16.0 | ≥30.00 | ≤16.0 | 0.80±0.10 | 50 |
| Φ40/19.0 | ≥40.00 | ≤19.0 | 0.80±0.10 | 50 |
| Φ51/25.4 | ≥51.00 | ≤25.4 | 0.80±0.10 | 25 |
| Φ65/32.5 | ≥65.00 | ≤32.5 | 1.30±0.20 | 25 |
| Φ78/38.1 | ≥76.00 | ≤38.1 | 1.30±0.20 | 25 |
english
français
Deutsch
Italiano
Русский
Español
português
Nederlandse
ελληνικά
日本語
한국
polski
فارسی
বাংলা
ไทย
tiếng Việt
العربية
हिन्दी
Türkçe
indonesia
Remarks: Custom sizes and colors are available upon customer request.
