Home > Products > Halogen Free Heat Shrink Tubing >

RoHS Compliant Printable Heat Shrink Tubing Flame Retardant Cable Heat Shrink Tubing Wear Resistant

RoHS Compliant Printable Heat Shrink Tubing

Flame Retardant Cable Heat Shrink Tubing

Cable Heat Shrink Tubing Wear Resistant

Place of Origin:

shenzhen, Guangdong, China

Brand Name:

XingQi

Certification:

RoHS2.0

Chat Now

Request A Quote

Product Details

Type:

Heat-Shrink Tube

Application Range:

Commercial, Industrial Environment

Shrink Ratio:

2:1/3:1

Color:

Black

Application:

Low Voltage,High Voltage,High Temperature,Industrial,waterproof Connection

Name:

Medium Wall Heat Shrinkable Tube (with/without Adhesive)

Highlight:

RoHS Compliant Printable Heat Shrink Tubing

Flame Retardant Cable Heat Shrink Tubing

Cable Heat Shrink Tubing Wear Resistant

Payment & Shipping Terms

Minimum Order Quantity

200M

Price

0.02-0.08usd/pcs

Packaging Details

carton，Customizable as per your demands.

Delivery Time

3-5 work days

Payment Terms

T/T

Supply Ability

8 million pcs/year

Printable Heat Shrink Marker Sleeve Cable Wire Identification Tubing 2: 1 3: 1 Flame Retardant Polyolefin Marking Tube

Product Introduction

Product structure:

Normal grade heat shrink marker sleeve is developed environment-friendly flame retardant heat shrinkable tube, using specially designed formulation of high polymers, through cross-link by electronic accelerator and continuous expansion.

Usage:

It can also be used for applications where limited fire hazard characteristics are necessary.

Working temperature:

-40 ºC ~ +125 ºC

Product Features

Shrink ratio: 3:1
Shrink temperature: 70ºC ~ 125ºC
Recommended Printers: : 3:1
Semi-rigid, insulated, excellent sealing performance

Basic Info

	Thickness	Semi-Rigid
	Materia	Polyolefin with an Inner Coating of Hot-Melt Adhes
	Resistant	Wear , Break Ou Resistant
	Working Temperature	125ºC
	Shrinktemperature	-125ºC

Color Standard color is white and yellow. Other colors are available if ordered.

Product Dimensions

Specification: Shrink Ratio-2X

As Supplied(mm)			After Recovery(mm)
ID (D)	Flatten Width (W)	Double Wall Thickness	ID (d)	Single Wall Thickness
ID (D)	Flatten Width (W)	Double Wall Thickness	ID (d)	Single Wall Thickness
2.00±0.20	3.7±0.3	0.48±0.10	≤0.79	0.45±0.06
2.79±0.20	5.0±0.3	0.48±0.10	≤1.18	0.49±0.06
3.64±0.23	6.3±0.4	0.48±0.10	≤1.59	0.51±0.06
5.26±0.25	8.9±0.4	0.49±0.10	≤2.36	0.54±0.06
6.92±0.28	11.5±0.4	0.50±0.10	≤3.18	0.56±0.06
10.2±0.32	16.7±0.5	0.51±0.11	≤4.75	0.59±0.06
13.5±0.36	21.8±0.6	0.52±0.11	≤6.35	0.60±0.07
20.1±0.40	32.2±0.6	0.53±0.11	≤9.53	0.62±0.07
26.7±0.45	42.5±0.7	0.55±0.12	≤12.7	0.63±0.07
39.8±0.51	63.2±0.8	0.57±0.12	≤19.1	0.64±0.07
53.0±0.56	83.9±0.9	0.58±0.13	≤25.4	0.64±0.08
79.4±0.56	125.3±1.0	0.59±0.13	≤38.1	0.64±0.09

Specification: Shrink Ratio-3X

As Supplied(mm)(mm)			After Recovery(mm)
ID(D)	Flatten Width(W)	Double Wall Thickness	ID(d)	Single Wall Thickness
2.00±0.20	3.7±0.3	0.47±0.10	≤0.53	0.52±0.06
2.79±0.20	5.0±0.3	0.47±0.10	≤0.79	0.57±0.06
3.64±0.23	6.3±0.4	0.48±0.10	≤1.06	0.61±0.06
5.26±0.25	8.9±0.4	0.49±0.10	≤1.59	0.67±0.06
6.92±0.28	11.5±0.4	0.50±0.10	≤2.36	0.71±0.06
10.2±0.32	16.7±0.5	0.52±0.11	≤3.18	0.77±0.06
13.5±0.36	21.8±0.6	0.53±0.11	≤4.75	0.80±0.07
20.1±0.40	32.2±0.6	0.55±0.11	≤6.35	0.84±0.07
26.7±0.45	42.5±0.7	0.56±0.12	<8.47	0.86±0.07
39.8±0.51	63.2±0.8	0.57±0.12	≤12.9	0.89±0.07
53.0±0.56	83.9±0.9	0.57±0.13	≤17.2	0.90±0.08
79.4±0.56	125.3±1.0	0.57±0.13	≤25.8	0.92±0.09
