Place of Origin:
shenzhen, Guangdong, China
Brand Name:
XingQi
Certification:
ISO9001/CUL
Working Temperature
-80ºC~+200ºC
Engineering Picture of FEP Heat Shrinkable Tube
Remark:Special specification and special colors could be customized by pening molds
Application
Mainly used for insulation and sheath, electrical components, wires, cables under various frequencies;
liquid crystal manufacturing apparatus, the single end emitting single core fiber tube,
heat exchanger,steam piping, high purity reagents conveying pipe, all kinds of corrosive medium conveying pipe.
|
As Supplied Inside Diameter(mm) |
After Recovery |
|
|
Inside Diameter(mm) |
Wall Thickness (mm) |
|
|
1.0±0.15 |
0.75 |
0.2-0.3 |
|
1.6±0.2 |
1.2 |
0.2-0.3 |
|
2.4±0.2 |
1.6 |
0.2-0.3 |
|
3.2±0.2 |
2.5 |
0.2-0.3 |
|
4.8±0.2 |
3.5 |
0.2-0.3 |
|
5.72±0.2 |
4.5 |
0.25-0.3 |
|
9.4±0.2 |
7.2 |
0.25-0.3 |
|
10.0±0.2 |
8.5 |
0.3-0.4 |
|
12.7±0.2 |
9.5 |
0.3-0.4 |
|
16.0±0.2 |
12.3 |
0.3-0.4 |
|
18.0±0.2 |
13.8 |
0.3-0.4 |
|
19.0±0.2 |
14.6 |
0.3-0.4 |
|
20.0±0.2 |
15.4 |
0.3-0.4 |
|
22.0±0.2 |
17 |
0.3-0.4 |
|
25.0±0.3 |
19.3 |
0.4-0.5 |
|
28.0±0.3 |
21.6 |
0.4-0.5 |
|
30.0±0.3 |
23.1 |
0.4-0.5 |
|
Color |
Clear,Black etc |
|
Melting Temperature ℃ |
260~270 |
|
Working Temperature C |
-80~200 |
|
Shrinkage Temperature °C |
200~250 |
|
Integrated Index g/10min4 |
12 |
|
Proportion |
2.15 |
|
Effect of Corrosion on Copper |
No Corrosion |
|
Antibacterial Property, Corrosion Resistance |
Good |
|
Toughness |
Good |
|
Tensile Strength MPA(KG f/cm) |
>21.0 |
|
The Decomposition Temperature C |
360 |
|
Flame Retardant |
VW-1 |
|
Resistance |
Abrasion Resistance, Acid and Alkali Corrosion, Anti Dipping, Anti Fungal, Anti Corona Discharge, Industrial Solvent, Resistance to Extemal Mechanical Damage |
|
Environmental Protection |
On the Human Body and No Harm to the Environment |
Remarks: Custom sizes are available upon customer request.
Our Company Advantages:
1. Direct factory with independent production, cost-effective and on-time delivery.
2. Full range of wiring harness sleeves, one-stop procurement.
3. Support customization: size, color, logo and special formulas available.
4. Reliable quality, compliant with UL, RoHS, REACH and other international standards.
5. Professional foreign trade service, support OEM/ODM, flexible for small and large orders.
