Place of Origin:
shenzhen, Guangdong, China
Brand Name:
XingQi
Certification:
RoHS 2.0
application
Made from modified radiation-crosslinked elastomer, it has excellent resistance to diesel oil, chemical reagents, high-temperature fluids, long-term heat resistance, and abrasion resistance. Used for protection of MIL‑Spec or commercial cableterminations, separation joints, etc.
Color
Standard color:
Black Remarks: Custom sizes and colors are available upon customer request.
Shelf Life and Storage
Store at -10°C to 40°C with relative humidity less than 75%, and has an expiration period exceeding five years.
Performance characteristics
| Operating Temperature: -55°C to 150°C | Voltage Rating: 600V |
| Compliant with SAE-AMS-DTL 23053/16 | Flame Retardant |
| Soft | Shrinkage ratio 2:1 |
| Minimum complete shrinkage temperature:175°C | RoHS Certification |
|
Performance Item |
Test Method |
Specification Requirement |
|
Tensile strength (MPa) |
ASTM D 2671 |
11.7Pa(Min) |
|
Elongation at Break (%) |
ASTM D 2671 |
250％(Min) |
|
Heat Aging (150°C /168hours) Tensile Strength |
UL 224 |
10.3 MPa (Min) |
|
Heat Shock (200°C/4 hours) |
ASTM D 2671 |
No cracks, no dripping |
|
Dielectric Strength |
ASTM D 2671 |
11.9kV / mm (Min) |
|
Flame retardancy |
ASTM D 2671 Proc.B |
60 seconds to self-extinguish. |
|
Volume Resistivity |
ASTM D 2671 |
10¹⁴Ω.cm(Min) |
|
Cold Bend(-30℃/1hours) |
ASTM D 2671 |
No cracking |
|
After solvent agingtensile strength,breaking tensilestrength |
ASTM D 2671, diesel70°C/24hours |
10.4 MPa (Min),200% (Min) |
| Inch | Available Sizes (mm) | Dimensions After Shrinkage(mm) | |
| D*(Min) | d*(Max) | w*(Min) | |
| 1/8 | 3.2 | 1.6 | 0.73 |
| 3/16 | 4.8 | 2.4 | 0.80 |
| 1/4 | 6.4 | 3.2 | 0.85 |
| 3/8 | 9.5 | 4.8 | 1.97 |
| 1/2 | 12.7 | 6.4 | 1.16 |
| 3/4 | 19.1 | 9.5 | 1.37 |
| 1 | 25.4 | 12.7 | 1.70 |
| 11/2 | 38.1 | 19.1 | 2.25 |
D*=Inner Diameter Before Supply d*= Inner Diameter After Shrinkage
w*=Wall Thickness After Shrinkage
Remarks: Custom sizes and colors are available upon customer request.
