Halogen Free Heat Shrinkable Tubes Environmental High Temperature Heat Shrink Tubing Black

Halogen Free Heat Shrinkable Tubes

Environmental High Temperature Heat Shrink Tubing

High Temperature Heat Shrink Tubing Black

Place of Origin:

shenzhen, Guangdong, China

Brand Name:

XingQi

Certification:

RoHS 2.0

Chat Now

Request A Quote

Product Details

Name:

Halogen‑Free Environmental High‑Temperature Resistant Flame Retardant Heat Shrink Tubing

Shrink Ratio:

2:1

Full Recovery Temperature:

≥ +135℃

Operating Temperature:

-55℃ ~ +150℃

Standard Colors:

Black

Highlight:

Halogen Free Heat Shrinkable Tubes

Environmental High Temperature Heat Shrink Tubing

High Temperature Heat Shrink Tubing Black

Payment & Shipping Terms

Packaging Details

carton，Customizable as per your demands.

Delivery Time

3-5 work days

Payment Terms

T/T

Halogen‑Free Environmental High‑Temperature Resistant Flame Retardant Heat Shrink Tubing

Product Introduction

Halogen‑Free Environmental High‑Temperature Flame‑Retardant Heat‑Shrink Tubing is composed of radiation‑crosslinked polyolefin material. It features flame retardancy, environmental performance, high temperature resistance, halogen‑free & antimony‑free characteristics with outstanding physical, chemical and electrical properties.

It provides electrical insulation for connectors under high‑temperature conditions, rust and corrosion protection for solder joints, mechanical protection and wire‑harness protection. Widely used in electronics, telecommunication, automotive, marine and aerospace manufacturing industries, especially suitable for household appliances such as electric aromatherapy furnaces, induction cookers, rice cookers, microwave ovens, ovens and so on.

Product Features

Standard: UL224

● Shrink ratio: 2:1

● Start shrink temperature: ≥ +84℃

● Full recovery temperature: ≥ +135℃

●Operating temperature: -55℃ ~ +150℃

● Compliance: RoHS2.0

● Good elasticity, low smoke, flexible, flame‑retardant

● Standard colors: Black, Red, Yellow, Blue, White (other colors available upon request)

Performance Item	Test Method	Specification Requirement
Tensile Strength (MPa)	ASTM D 2671	≥10.4
Elongation at Break (%)	ASTM D 2671	≥200
Tensile Strength after Thermal Aging (MPa)	180°C × 168h	≥7.3
Elongation at Break after Thermal Aging (%)	158°C × 168h aging per ASTM D 2671	≥100
Withstand Voltage (Rated 600V)	UL 224	No breakdown at 2500 V for 1 min
Dielectric Strength (Alternative to Withstand Voltage) (kV/mm)	ASTM D 149	≥15
Longitudinal Change (%)	ASTM D 2671 Method C	-5 ~ +5
Flame Retardancy	ASTM D 2671Method C	vw-1
Thermal Shock	UL224(250°CX4h)	No cracks, no dripping
Volume Resistivity (Ω·cm)	IEC 60093	≥1×10¹⁴

Product Dimensions

Size (mm)	Inner Diameter Before Shrinking (mm)	Max. Inner Diameter After Full Shrinking (mm)	Wall Thickness After Full Shrinking (mm)	Standard Packaging (m/roll)	Suitable Range (mm)
Φ1.0	1.5±0.2	≤0.65	0.38±0.10	200	0.75～1.00
Φ1.5	2.0±0.2	≤0.85	0.40±0.10	200	0.95～1.40
Φ2.0	2.5±0.2	≤1.00	0.44±0.10	200	1.10～1.80
Φ2.5	3.0±0.2	≤1.25	0.44±0.10	200	1.40～2.20
Φ3.0	3.5±0.2	≤1.50	0.44±0.10	200	1.65～2.60
Φ3.5	4.0±0.2	≤1.75	0.44±0.10	200	1.95～3.00
Φ4.0	4.5±0.2	≤2.00	0.44±0.10	200	2.20～3.40
Φ4.5	5.0±0.2	≤2.25	0.44±0.10	100	2.50～3.80
Φ5.0	5.5±0.2	≤2.50	0.56±0.10	100	2.80～4.20
Φ6.0	6.5±0.2	≤3.00	0.56±0.10	100	3.30～5.00
Φ7.0	7.5±0.3	≤3.50	0.56±0.15	100	3.90～5.75
Φ8.0	8.5±0.3	≤4.00	0.56±0.15	100	4.40～6.50
Φ9.0	9.5±0.3	≤4.50	0.56±0.15	100	5.00～7.30
Φ10	10.5±0.3	≤5.00	0.56±0.15	100	5.50～8.10
Φ11	11.5±0.3	≤5.50	0.56±0.15	100	6.10～8.90
Φ12	12.5±0.4	≤6.00	0.56±0.15	100	6.60～9.60
Φ13	13.5±0.4	≤6.50	0.69±0.15	100	7.20～10.40
Φ14	14.5±0.4	≤7.00	0.69±0.15	100	7.70～11.20
Φ15	15.5±0.4	≤7.50	0.69±0.15	100	8.30～12.00
Φ16	16.5±0.4	≤8.00	0.69±0.15	100	8.80～12.80
Φ17	17.5±0.4	≤8.50	0.69±0.15	100	9.40～13.60
Φ18	19.2±0.5	≤9.00	0.77±0.15	100	9.90～14.90
Φ20	22.0±0.5	≤10.0	0.77±0.15	100	11.00～17.20
Φ22	24.0±0.6	≤11.0	0.77±0.15	100	12.10～18.70
Φ25	26.0±0.6	≤12.5	0.87±0.20	50	13.80～20.30
Φ28	29.0±0.6	≤14.0	0.87±0.20	50	15.40～22.70

Remarks: Custom sizes and colors are available upon customer request.
